Lesson 2: Choosing your soldering iron

There is a particular kind of frustration that belongs entirely to bad tools.

You do everything Lesson 1 told you. The tip goes on the joint first. You wait. You feed the solder in from the far side. And nothing happens. The solder sits there like a small silver pebble, refusing to melt, while you press harder and wait longer and start to wonder whether you are simply not very good at this.

You are probably fine. Your iron has run out of heat.

This is the most common reason beginners give up, and it is almost never diagnosed correctly, because the iron feels hot. It burns you if you touch it. It says 350 on the side. It just cannot deliver heat into a piece of metal at the rate the metal takes it away, and the moment it meets a real joint it collapses.

So this lesson is about buying an iron that will not do that to you. It is deliberately only about the iron. Everything else you need, stands, cutters, cleaning, the useful extras, is Lesson 4, and you should read this one before you spend anything.

By the end of this lesson you will be able to tell a genuinely capable iron from an expensive-looking one, understand why the specification everyone quotes is the wrong one, and know what your power source has to do with any of it.

2.1 What an iron actually has to do

The aim of this section is to define the job properly, because once you know what the tool is for, the specifications stop being a list of numbers and start being answers to a question.

Lesson 1 said the whole craft is getting metal hot enough and clean enough that solder wants to spread. So the iron has exactly one job: move heat into the joint faster than the joint can carry it away.

That second half is the part people miss. A pad is not a passive thing sitting there warming up. It is soldered to copper, that copper runs off across the board as tracks, and all of it is quietly conducting your heat away and dumping it into the rest of the board. Some pads do this gently. Some are attached to a large area of copper and drain heat almost as fast as you can supply it, which is why Lesson 7 spends time on reading a board before you touch it.

So the real question is not "how hot does the tip get?" It is: when the tip touches cold metal and its temperature drops, how quickly does the iron put that heat back?

That property is called thermal recovery, and it is the single thing that separates an iron that feels effortless from one that feels like a fight. It is also almost never printed on the box.

Two irons can both claim 350 °C. Touch a joint with the first and the tip falls to 250 °C and stays there, so the solder never melts and you sit pressing harder while heat leaks into your component. Touch the same joint with the second and the tip dips briefly, the heater responds, and it is back at temperature before you have finished thinking about it. Same number on the display. Completely different tool.

Figure 2.1: The moment that matters. The tip's temperature drops as soon as it meets cold metal. What separates a good iron from a poor one is how fast it climbs back.

2.2 Temperature control, and why wattage is a poor guide

The aim of this section is to settle the single most important decision you will make, which is not the one most buying guides lead with.

Soldering irons come in two fundamentally different kinds, and the gap between them is much larger than the gap between any two irons of the same kind.

Unregulated irons are the cheap ones. Inside there is a heating element and nothing else. You plug it in, it gets hotter, and it keeps getting hotter until the heat escaping into the air happens to balance the heat going in. Whatever temperature that lands on is your temperature. It is not chosen, measured, displayed or held. It drifts with the room, with the tip you fitted, and with how long it has been sitting there.

They fail in two directions at once. Left idle, they climb well past where they should be and cook the tip, which oxidizes and stops transferring heat properly, which is Lesson 6's subject. Put under load, they have no way of knowing they have gone cold, so they simply stay cold.

Temperature-controlled irons have a temperature sensor and a control loop. The iron measures the tip many times a second, compares it to the number you set, and adjusts the power going into the heater. Idle, it holds steady instead of climbing. Loaded, it notices the drop immediately and pushes power in to correct it.

That closed loop is the whole game, and it is the thing worth paying for. If your budget only stretches to one improvement, make it this one.

Why wattage is the wrong headline

Wattage is the number every listing shouts, and it is the number that misleads most.

Wattage describes the maximum power the heater can draw. It says nothing about whether the iron knows when to draw it. A 100 W unregulated iron has a great deal of power and no idea what to do with it, so it wanders hot when you are not using it and offers you nothing extra when you are. A 60 W regulated iron with a fast sensor will out-perform it on every joint you are likely to make.

Power matters, but only as a ceiling. You want enough headroom that the iron can respond hard when it needs to. Beyond that, more watts on the box buys you nothing.

A useful way to hold it: wattage is how big the tap is, temperature control is whether anybody is watching the sink.

Figure 2.2: An unregulated iron drifts hot when idle and collapses under load. A temperature-controlled iron holds its setting and recovers.

2.3 The tip is most of the iron

The aim of this section is to redirect your attention to the part that does the work, because people buy the handle and inherit the tip.

Everything the iron does, it does through about a centimeter of metal at the end. That piece decides how much heat reaches your joint, how quickly, and how precisely.

Cartridge tips and why they are worth having

In an older design, the heating element lives in the handle and the tip is a separate piece of metal that slots on in front of it. Heat has to travel from the heater, across a mechanical joint, into the tip, and then into your work. The temperature sensor, meanwhile, is back at the heater, measuring a place that is not where the soldering is happening.

In a cartridge design the heater, the sensor and the tip are one integrated part. The heat is generated millimeters from your joint and the sensor is right there with it. Recovery is faster, and the number on the display means something closer to the truth, because it is measured near the work rather than inferred from further back.

You change the tip by pulling out the whole cartridge and pushing in another. It costs more per tip, and it is the reason a good modern iron feels so responsive.

T12 is the most common cartridge format you will meet, originally a Hakko design and now made by many manufacturers, in a very large range of shapes. That popularity is worth more than it sounds: it means replacements are cheap, available everywhere, and will still be available in five years.

You will also meet the older arrangement, usually under the tip name 900M, which is what the extremely common 936-style stations use. Those are not bad tools, and plenty of them are properly temperature controlled. But the heater and the sensor live in the handle with the tip pushed on in front, so recovery is slower and the temperature being measured is further from your work than the number on the display implies. It is a useful name to know, because it tells you at a glance which generation of design you are looking at. Between two stations at a similar price, the cartridge one will usually feel better to solder with.

Shape: why the pointy one is usually wrong

This is the part that surprises people. The instinct is to reach for the finest, sharpest, most needle-like tip, on the reasonable-sounding theory that a small tip is a precise tip.

It is the wrong instinct, and Lesson 1 already explained why. A sharp conical tip touching a round component leg makes contact at very nearly a single point, and heat crosses a single point extremely slowly. You end up with a precise tool that cannot deliver any heat, so you press harder and hold longer and cook the component you were being careful with.

A chisel or bevel tip has a flat face. Laid into the angle where the leg meets the pad, it makes real contact with both at once, and the joint comes up to temperature in about a second. It is more precise in practice than a conical tip, because it does the job quickly enough that you are not sitting on the joint hoping.

For general through-hole work, a chisel tip somewhere around 1.5 to 2.5 mm across covers almost everything. Fine conical tips have their uses, mostly in surface-mount work, which is Lesson 12.

When you buy, check what replacement tips cost and how easy they are to get. An iron with an unusual proprietary tip can become unusable the moment the manufacturer loses interest.

Figure 2.3: A conical tip touches a round leg at almost a single point. A chisel tip lies into the joint and contacts the leg and the pad at once.

2.4 How it is powered, and why that sets your ceiling

The aim of this section is to explain a genuine catch in modern irons that very few people mention before you have bought one.

Traditionally a soldering iron plugs into a wall. Inside the base station is a transformer, and it supplies the same power today as it did last year. There is nothing to think about.

A newer generation of irons is powered over USB-C, using USB Power Delivery. These are small, they have no base station, and they will run from a laptop charger or a power bank. That is genuinely useful, and it is why they have become popular.

But there is a catch, and it is a real one. A USB-C supply does not simply provide power. It negotiates. The iron asks the supply what voltages it can offer, the supply answers, and they agree on one. And the voltage they agree on determines how much power the iron can draw, which determines how hot it can get and how fast it recovers.

So the same iron, plugged into two different chargers, is two different tools.

Plug it into a laptop's USB port at 5 V and there is very little power available. The iron will still work, and for small joints it may be fine, but its maximum temperature is capped a long way below its rated figure, and its recovery under load will be poor. Plug the same iron into a 65 W supply that can deliver 20 V and it reaches its full temperature and recovers properly.

Here is the amomii Quill's own version of that table, which is typical of the category:

That is not a small difference, and it is worse than the numbers first suggest.

Common lead-free alloys melt somewhere around 217 to 227 °C. So a tip capped at 220 °C is not comfortably above the melting point, it is sitting right on it. And section 2.1 already told you why that is fatal: the tip's temperature is not the joint's temperature. The instant that tip touches cold copper, heat drains out of it, and the joint arrives at something below whatever the display says. To bring a joint up to melting point, the tip has to be meaningfully above it.

At 5 V you do not have a slightly underpowered iron. You have no thermal headroom at all, and the solder will simply sit there being a pebble. On a laptop port a USB-C iron can be genuinely unable to do the job, through no fault of its own.

None of this makes USB-C irons bad. It makes the supply part of the tool. If you buy one, use the supply it came with, or check that whatever you plug it into can deliver 20 V and enough wattage. And if a listing does not tell you what the iron does on different supplies, treat that as information about the seller.

Figure 2.4: With a USB-C iron the power supply is part of the tool. The voltage it negotiates sets the highest temperature the iron can reach.

2.5 Station or pencil: an honest comparison

The aim of this section is to give you the case for the option we do not sell, because there is a good one.

The small USB-C irons get most of the attention at the moment, and we make one. It would be easy to write this section as though the old approach had been superseded. It has not.

A dedicated mains station has real advantages, and they are not nostalgia:

• Its power never varies. No negotiation, no wondering what your charger is capable of. It supplies what it supplies, every time.
• There is usually more of it. Stations tend to have more power in reserve, which shows up exactly where beginners struggle: large pads, ground planes, thick wires, connector shells.
• It is more stable to work at. A weighted base, a proper cradle for the iron, and a short flexible lead from the base to your hand rather than a stiff charger cable pulling at your wrist.
• It is cheaper per watt, and mid-range stations have been refined over decades.
• It grows. Many stations take hot air handpieces and desoldering guns on the same base.

What you give up: it is a box on your desk permanently, it is tied to a mains socket, and it does not travel.

A USB-C pencil iron has the opposite profile:

• It is very small, so it goes in a drawer, in a bag, or in a kit box.
• It runs off things you already own, including a power bank, which means you can solder somewhere without a mains socket.
• Nothing has to live on your desk.

What you give up: the supply becomes part of the tool, as section 2.4 explained, and there is generally less power in reserve at the top end.

So which one

If you have permanent bench space and you expect to keep soldering, a decent temperature-controlled station is an excellent purchase and may well serve you better than anything we sell. That is not a polite concession, it is the honest answer to a common situation.

If you work at a kitchen table and everything has to be put away afterwards, or you want to work somewhere without a socket, a USB-C iron is the better tool and the compromise is one you will not often notice.

What matters far more than the format is section 2.2: whichever you buy, buy a temperature-controlled one.

Figure 2.5: The honest trade. A station gives steadier power and more of it. A USB-C pencil gives portability and takes up no permanent space.

2.6 The checklist, and what to ignore

The aim of this section is to make this decidable in a couple of minutes in front of a listing.

Worth having

• Adjustable, sensor-based temperature control, with the temperature shown. Non-negotiable. Everything else is a preference.
• A cartridge tip in a common format, with replacements that are cheap and easy to find.
• A chisel or bevel tip for general work.
• Enough power in reserve that it recovers rather than sags. Look for reviews that mention how it behaves on large pads.
• Automatic power-off. It sounds like a small convenience. It is the feature that means an iron left on by accident switches itself off instead of sitting at 350 °C in an empty room.
• Tip calibration, if offered. Useful once you have a way to check the real temperature, and harmless until then.
• Certification marks that actually apply where you live, and a seller who is specific about which ones.

Safe to ignore

• Headline wattage, on its own. See section 2.2.
• A very high maximum temperature. You will spend nearly all your time between 300 and 350 °C, and running hot shortens tip life for no benefit.
• A large bundle of tips. You will use one or two. A pile of shapes you will never fit is not value.
• Color screens, apps, lighting. None of it moves heat into a joint.

2.7 What we make, and why

The aim of this section is to tell you plainly what our commercial interest is, and then give you enough reasoning to disagree with us.

We should say the obvious thing first. We are amomii. We make a soldering iron, we would like you to buy it, and of course we recommend it, because it is ours. Nobody should have to guess at that.

What is more useful is why it exists at all.

We did not set out to sell soldering irons. We make electronics kits that people learn to solder on, and for years we watched beginners struggle with their iron rather than with the soldering. Cheap unregulated irons were producing exactly the failure this lesson opened with, and the affordable regulated ones were bench stations that made no sense to someone building a kit on a kitchen table.

So we went looking for something to put in the box: temperature controlled, quick to recover, a tip standard that would still be buyable in five years, safe enough to leave near a beginner, small enough to store, and cheap enough not to double the price of a kit. Nothing hit all of it at the price we needed. So we had one made.

If something had, we would have bought it and put that in the box instead, and saved ourselves a great deal of trouble.

amomii Quill

Where it is not the answer

• It is a USB-C iron, so section 2.4 applies to it in full. On a laptop port it tops out at 220 °C, which is not enough for most lead-free work. Use the supply that comes with it.
• It carries CE and RoHS certification, and no others. If you need a particular mark for where you live or work, check that first.
• If you have permanent bench space, a good mains station may suit you better, for all the reasons in section 2.5. We would rather you bought the right tool than ours.

amomii Quill is not on sale yet. It is finished and it is coming. If you need an iron today, buy one from section 2.6's checklist instead. We would rather you were soldering.

What this sets up

You now know what you are buying and why. Three things follow directly:

What else you need is Lesson 4, and the honest answer is: much less than you think, and none of it urgently.

Why your tip needs looking after is Lesson 6. A neglected tip stops transferring heat, and at that point the quality of the iron underneath it stops mattering.

Why some joints will fight you even with a good iron is Lesson 7, and it comes down to where the heat goes once it leaves your tip.

Frequently asked questions

What temperature should I set my soldering iron to? Most through-hole work sits between 300 and 350 °C. Start at 320 °C, and raise it only if joints are slow to take. Running hotter than you need shortens tip life and risks the component, and it does not make the solder flow better once you are comfortably above its melting point.

How many watts should a soldering iron be? It matters less than you would think. Wattage sets the ceiling, not the responsiveness. A 60 W temperature-controlled iron will comfortably out-perform a 100 W unregulated one. Aim for temperature control first and treat wattage as headroom.

Is a temperature-controlled soldering iron worth it for a beginner? It is the one upgrade that matters most, and it matters most precisely because you are a beginner. An unregulated iron produces failures that look like your fault, which is a discouraging way to learn.

Can I use a USB-C soldering iron with any charger? It will run, but the charger sets the ceiling. At 5 V from a laptop port, a USB-C iron is limited to a temperature below what most lead-free solder needs. Use the supply it came with, or one that can deliver 20 V with enough wattage.

What is the difference between T12 and 900M tips? T12 is a cartridge: the heater, the sensor and the tip are one part, generated millimeters from your joint. 900M is the older style, used by common 936-type stations, where the heater and sensor stay in the handle and the tip pushes on in front. Both work. T12 recovers faster and measures closer to where the work is happening.

What tip should I use for general soldering? A chisel or bevel tip around 1.5 to 2.5 mm. It contacts the leg and the pad at the same time, so heat crosses quickly. Fine conical tips look more precise and usually work worse, because they touch a round leg at almost a single point.

Do I need a soldering station, or is a pencil iron enough? Both work. A station gives steadier power, more of it in reserve, and a stable place for the iron to live. A pencil iron is portable and takes up no permanent space. If you have a bench, a station is a fine choice; if you work at a table and put things away, a pencil iron is better. Temperature control matters far more than which format you pick.

Why won't my solder melt even though the iron is hot? Most often the iron cannot deliver heat fast enough into the joint, which is thermal recovery, not temperature. Other common causes are a dirty or un-tinned tip (Lesson 6) and a pad connected to a large area of copper (Lesson 7).

Next

Lesson 3: Solder and flux, explained. Leaded versus lead-free told straight, including the parts nobody enjoys saying out loud, and why flux matters more than the solder does.
